Chauvet Professional Net-X-II Ethernet to DMX Node

Get Flexible Network and DMX Routing with the Chauvet Professional Net-X-II Ethernet to DMX Node

A versatile rack-mountable Ethernet-to-DMX node and merger that converts Art-Net or sACN to eight individually assignable DMX outputs and supports DMX preset recording. Perfect for creating a reliable and highly customizable network infrastructure for complex lighting control systems in touring, production, and installation environments.

• Features two 5-pin DMX inputs and eight optically isolated 5-pin DMX outputs.
• Converts up to eight DMX universes into Art-Net or sACN network protocols.
• Merges two controllers using HTP or LTP protocols for flexible signal management.
• Records up to 10 DMX presets for standalone playback or remote contact triggering.
• Supports RDM over Art-Net for simplified remote fixture configuration and management.
• Includes an integrated webserver for remote setup, system backup, and firmware updates.

Net-X II is a versatile rack-mountable Ethernet-to-DMX node, which also functions as a merger for two controllers on either Ethernet or DMX inputs. It has the ability to record up to 10 DMX presets, which can be triggered remotely. Net-X II has two 5-pin DMX inputs and eight 5-pin DMX outputs – all optically isolated, and can output up to eight universes simultaneously. The eight 5-pin DMX outputs can be individually assigned to either of the two DMX inputs (or the Ethernet inputs to mix network inputs with DMX inputs in a single device). LTP and HTP merging fully supports network protocols sACN, Art-Net or DMX to merge two incoming controllers to any DMX output. It has RDM over network functionality. Net-X II provides a reliable platform for novice users with its preset configuration library, while providing experts with a highly customizable network infrastructure for complex control systems.

5-Pin DMX Splitter

Functions as a versatile 5-pin DMX splitter and distributor for your lighting rig.

Network to DMX Conversion

Converts Art-Net or sACN network data into as many as eight standard DMX universes.

DMX to Network Conversion

Converts up to eight standard DMX universes into Art-Net or sACN network protocols.

Advanced Merging Capability

Merges two 5-pin DMX inputs or two network controllers into a single DMX universe output.

HTP and LTP Merging

Supports both Highest Takes Priority (HTP) and Latest Takes Priority (LTP) for merging DMX signals.

Configuration Backup and Restore

Allows you to backup and share settings and configurations with other Net-X II units.

Integrated Webserver

Features a built-in webserver for remote configuration, backup, and firmware updates.

Onboard Scene Recording

Record and store lighting looks into memory for standalone playback triggered by external contacts.

RDM Over Art-Net

Supports Remote Device Management (RDM) over Art-Net for easy remote fixture management.

SPECIFICATIONS

Construction and Physical

• Dimensions: 19 x 6.22 x 1.73 in (483 x 158 x 44 mm)
• Weight: 4.6 lb (2.1 kg)
• Threaded Bolt: M12
• Exterior Color: Black
• Housing Material: Steel
• Rackmount: 1U

Connections

• Power Connection: Edison (Local) plug to Seetronic powerKON
• Power Input: Seetronic powerKON
• Device Data Inputs: Seetronic powerKON (1 total) and 5-pin XLR (2 total)
• Device Data Outputs/Inputs (Assignable): 5-pin XLR (8 total)
• Device Date Throughputs: Seetronic etherKON (1 total)
• Cable Length (Power): 5 ft (1.5 m)

Control

• Control Protocol: Art-Net, DMX, sACN
• Merge Support: Yes
• Protocol Merging: (2) Art-net consoles, (2) DMX consoles, (2) sACN consoles

Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 11 W, 0.09 A @ 120 V, 60 Hz
• Power and Current: 14 W, 0.06 A @ 208 V, 60 Hz
• Power and Current: 14 W, 0.06 A @ 230 V, 50 Hz

Certifications and Qualifications

• Certifications: CE
• IP Rating: IP20, dry location
• Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

Required Accessories

• Compatible Mounting Options: M12 Bolt/Clamp
