Shure MXA310 Table Array Microphone - White

Captured Sound Accurately with the Shure MXA310 Table Array Microphone

Organizational clarity takes focused discussion. But how can you conference effectively if you can’t be heard clearly on the call? The MXA310 maximizes audio quality so voice comes through cleanly.

Seamless Integration and Security

The MXA310 connects to the vast ecosystem of Shure and third-party networked audio devices via Dante or AES67, with just one cable for power, control and audio. Also, Shure Network Audio Encryption can be enabled when used with the IntelliMix P300 Audio Conferencing Processor or Shure Audio Network Interfaces, which utilize AES-256 technology to protect confidential content.

Control of the Sound You Get

Office HVAC systems can add overpowering background noise to the call. The Shure-exclusive "toroid" polar pattern only captures table-level sound, helping to reduce unwanted distractions from fan or HVAC noise. Additionally, with Steerable Coverage™ and built-in automatic mixing, you can capture every voice with pinpoint accuracy anywhere in the room.

Easy Maneuverability with Great Aesthetics

The MXA130 includes a programming-free LED mute sync with leading software conferencing solutions including Zoom Rooms, Microsoft Teams and Skype for Business (when used with IntelliMix P300 or ANIUSB-MATRIX). It also has a neat LED light ring with configurable colors and brightness control.

SPECIFICATIONS

General

• Polar Pattern (All channels independently adjustable): Cardioid, Hypercardioid, Supercardioid, Toroid, Omnidirectional, Bidirectional
• Connector Type: RJ45
• Power Requirements: Power over Ethernet (PoE), Class 0
• Power Consumption: 4W, maximum
• Weight: 362 g (0.8 lbs)
• Dimensions (H x W x D): 3.6 x 13.4 x 13.4 cm / 1.4 x 5.3 x 5.3 in
• Control Application: HTML5 Browser-based
• Operating Temperature Range: −6.7°C (20°F) to 40°C (104°F)
• Storage Temperature Range: −29°C (-20°F) to 74°C (165°F)

Audio

• Frequency Response: 100 to 20,000 Hz
• Dante Digital Output
• Channel Count: 5 total channels (4 independent transmit channels, 1 Automatic mixing transmit channel)
• Sampling Rate: 48 kHz
• Bit Depth: 24
• Sensitivity (at 1 kHz, -15 dB Gain Setting): -21 dBFS/Pa
• Maximum SPL (1 kHz at 1% THD, -15 dB Gain Setting): 115.2 dB SPL
• Signal-To-Noise Ratio (94 dB SPL at 1 kHz, -15 dB Gain Setting): Cardioid 75 dB, Toroid 67 dB
• Latency (not including Dante latency): less than 1 ms
• Self Noise (-15 dB Gain Setting): Cardioid 19.2 dB SPL-A, Toroid 26.8 dB SPL-A
• Dynamic Range (-15 dB Gain Setting): Cardioid 96 dB, Toroid 90 dB SPL
• Built-in Digital Signal Processing
• Per Channel: Equalizer (4-band Parametric), Mute, Gain (140 dB range)
• System: Automatic mixing, Low-Cut Filter (-12 dB/octave @150 Hz)
